• Fan Input Voltage: 24V DC


• Heater Input Voltage:220V


• Power: 350W�20%


• Size: 87.5*60*42mm?Includes mounting holes?


• Mounting hole size:?4mm


• Heat material: PTC Thermistor


• Heat methods: heat radiation by air flow


• Lead wire: high temperature line


• The length of lead wires: 200mm


• length of bare wires: 10mm


• Surface insulate: No


• Use: this PTC part is used for heating air or solid. the PTC material has a characteristic that it is constant temperature on the surface.

Notice: the power is reference value. the better the dissipation is, the bigger the power is.In different working environments, power will have a plus or minus 20% tolerance.

• If you have strict requirements on power accuracy, this product is not suitable for you.

advantage

• Safety


• Heat up quickly, long service life.


• self-control temperature


• small sound

application

• Equipment


• Heater


• General Electric appliance


• Air curtain machine

PTC Insulative corrugated heater (PTC Air heater insulator Heater for warm air-conditioner) is a kind of large power Non-Surface-Electrified PTC heater with wind blowing element is fixed in aluminium tube and keep insulated with the alumium tube.
