The 400 V / 68 µF aluminum electrolytic capacitor provides high‑voltage bulk storage with low ESR, ensuring stable voltage regulation and minimal ripple in demanding power‑conversion circuits. Its polarized construction is optimized for reliable operation in high‑stress environments.

• Voltage Rating: 400 V DC


• Capacitance: 68 µF (±20 %)


• Dielectric Type: Aluminum electrolytic


• Temperature Range: –40 °C to +105 °C


• ESR: Low, suitable for high‑frequency SMPS filtering


• Dimensions: Standard radial leaded package (exact footprint per datasheet)


• Mounting: Through‑hole, polarized leads for easy insertion


• Compliance: RoHS‑compliant, IEC 60384‑1

Key Benefits

• Excellent voltage handling for input‑filter stages in switch‑mode power supplies.


• Stable capacitance over a wide temperature range, reducing performance drift.


• Low equivalent series resistance (ESR) minimizes heat generation and improves efficiency.


• Robust construction for long‑term reliability in UPS, inverter, and motor‑drive systems.


• Polarized design eliminates risk of reverse‑bias damage when installed correctly.

Typical Applications

• SMPS input and output filters


• Uninterruptible Power Supplies (UPS)


• Inverter and motor‑drive power stages


• Industrial control panels and PLC power supplies


• Audio power amplifiers requiring bulk storage


• High‑voltage DC‑link circuits

Installation Guidelines

• Observe correct polarity; the negative lead is marked on the case.


• Ensure adequate clearance from high‑temperature components to maintain rated lifespan.


• Use appropriate soldering temperature and time to avoid damage to the electrolyte.


• Verify that the circuit voltage does not exceed 400 V DC under normal operating conditions.


• For high‑frequency applications, keep lead length as short as possible to reduce parasitic inductance.
