CD 4049

RWF 500

CD 4049IC is capable to drive two TTL loads. The main use of this IC is to create a voltage multiplier circuit by simply adding resistor, capacitor, and diode with it.


Product Description

IC 4049 consists of six NOT gate inside it and having a high input supply voltage with a maximum current rating of 1mA at 18v.

Specifications

  • Mostly used in voltage multiplier circuit

  • Accept High input supply voltage

  • Used to low the high logic levels

  • High sink current for driving two TTL loads

  • Special input protection allows input voltages greater than VDD

  • 100% Tested for Quiescent Current at 20 V

  • Available packages: PDIP, SOIC, TSSOP, SO with 16 number of pins

  • Maximum input current of 1uA at 18v over full package temperature range

  • Compatible in use with breadboard and perf board

  • Input supply voltage ranges from 3v (min.) to 18v (max.)

  • Supply current 50mA (max.)

  • Ambient Temperature ranges from -40 to +85�C

  • Input capacitance is 22.5pf (max.)

  • As input voltage increase from 5v to 15v, output current sink also vary from 1.8 to 26mA
