• Model: ELP-USBFHD01M-L21


• Sensor: OV2710


• Lens Size:1/2.7 inches


• Pixel Size:0um X 3.0um


• image area:5856 �m x 3276 �m


• Resolution: FULL HD 1920(H)X1080(V)


• Compression format: JPEG / YUV2(YUYV)


• Resolution & frame:320X240 QVGA MJPEG @120fps/ 352X288 CIF MJPEG @120fps
  640X480 VGA MJPEG@120fps/ 800X600 SVGA MJPEG@60fps
  1024X768 XGA MJPEG@30fps/ 1280X720 HD MJPEG@60fps
  1280X1024 SXGA MJPEG@30fps/ 1920X1080 FHD MJPEG@30fps


• Special function: Lens correction/ Defective pixel correction/ Black sun cancellation


• Min illumination:05lux


• Shutter Type: Electronic rolling shutter / Frame exposure


• Sensitivity:7V/lux-sec@550nm


• Connecting Port type:0 High Speed(Support USB2.0 HS/FS, USB2.0 OTG)


• USB Protocol:0 HS/FS USB1.1/USB1.0


• Connecting Port type:0 High Speed


• OTG Protocol's 2.0 OTG


• Free Drive Protocol's Video Class (UVC)


• AEC: Support


• EPassport


• AGC:Support


• Adjustable parameters: Brightness, contrast, saturation,hue,sharpness,Gamma,White balance, Backlight contarst,Exposure


• Lens Parameter:1/2.8/3.6/6/8/12/16mm/no distortion/fisheye lens optional


• Night vision: Support, need to equipped IR sensor 850nm or 940nm lens and IR LED Board


• LED board power connector: Support 2P-2.0mm socket


• Power supply's BUS POWER 4P-2.0mm socket


• Operating Voltage: DC5V


• Working current: Working current


• Working temperature:0~60?


• Stragetemperature:-20~75?


• Board size /Weight:38X38mm (Compatible 32X32mm)/ about 30g


• Cable: Standard 1M (optional 2M,3M,5M)


• Operating system request:WinXP/Vista/Win7/Win8/Win10/Win11 Linux with UVC(above linux-2.6.26)
  MAC-OS X 10.4.8 or later
  Wince with UVC
  Android 4.0 or above with UVC

Features

High Speed 1080P HD USB Camera
Equiped with 3.6 mm wide angle lens
Can drive 30fps@1080P and 60fps@720p, 120fs at 480P
CMOS 1080P sensor for high quality image and low power consumption.
High speed USB 2.0 interface for high resolution PC camera interface.
high pixel technology for sharp image and accurate color reproduction.
low light performance � ideal for any lighting condition.
Super small outline and thin profile for embedded applications.
High frame rate� deliver 60 fps in 1280X720 resolution,30 fps in 1920X1080 resolution.
High quality lens, true and undistorted color image.
Low power consumption � ideal for portable equipment.
UVC for use in Linux, Windows XP, WIN CE, MAC, SP2 or above.
Camera with UVC.
