KA3005P is a high-quality laboratory power supply for constant voltage and constant current operation. It features a finely adjustable current and voltage setting, separate displays for output current/output voltage, 5 memories for quickly recallable current/voltage settings and protection devices against overvoltage and overcurrent. Specifications

• Model




• KA3005P




• Voltage / current range




• Output Voltage Range :0-30V




• Output Current:5A




• Load regulation




• : 0.01% +2 mV voltage / current: 0.1% +5 mA




• Linear regulator




• : 0.01% +3 mV voltage / current: 0.1% +3 mA




• Set the resolution




• Voltage: 10mV / current: 1mA




• Setting accuracy (25 + - 5 )




• : 0.5% +20 mV voltage / current: 0.5% +10 mA




• Ripple (20hz-20M)




• Voltage: 2mVrms / current: 5mArms




• Temperature Coefficient




• : 100ppm +10 mV voltage / current: 100ppm +5 mA




• Readback resolution




• Voltage: 10mV / current: 1mA




• Readback temperature coefficient




• Voltage: 100ppm +10mv / current: 100ppm +5 mA




• Reaction time (10% of the rated load)




• Voltage: 100mS / current: 100mS




• Operating environment




• Indoor use




• Altitude: 2000m




• 0 ~ 40 ambient temperature




• 80% relative humidity




• Fitting




• Manual, power cord (1.2M)




• Weight and dimensions




• 3 kg / 110 (W) X156 (H) X 260 (D)




• Storage environment




• Ambient temperature -10 - 70




• 70% relative humidity
